USED 2004 CITIZEN CINCOM L-20

£18,000
Send Inquiry

Overview

Type
Swiss Type Automatic Screw Machines
Manufacturer
CITIZEN
Model
CINCOM L-20
Year
2004
Stock #
19
Status
for sale

Description

CITIZEN CINCOM L-20 Swiss Type Automatic Screw Machine from 2004 in used condition. Ideal for precision machining needs. Known for reliability and efficiency. Perfect for improving your production capabilities.

Specifications

Spindle Hole Dia0.787"
Power5hp
RPM10000rpm
# Axis7
ControlCNC (Mitsubishi Meldas 635)
Dimensions 88 x 46 x 62 in "
Weight2300
Max. Machining Diameter: 20mm Max. Machining Length: 200mm Max Front Drilling Diameter: 10mm Max Front Tapping: M6 Spindle Through Hole Diameter: 24mm Max Front Spindle Speed: 10,000rpm Max Back Spindle Drilling: 8mm diameter Max Back Spindle Tapping: M6 Max Back Spindle Speed: 8,000rpm Main Spindle C Axis: 0.001 Degrees Max chuck diameter of the back spindle: 20mm Max Workpiece protrusion length from the back spindle: 30mm Max Back Spindle Speed: 8,000 RPM Rotary Tools On Gear Post Maximum Drilling: 7mm Diameter Rapid Feed Rates (All Axes): 20m/min Axis Travel: X1 Axis: 45.5mm Y1 Axis: 294mm Z1 Axis: 2055mm X2 Axis: 316mm Z2 Axis: 180mm Main and back spindle Indexing: 0.1 degrees Main and back spindle 'C' Indexing: 0.001 degrees Bar Feeder Length: 4270mm Centre Height: 1,050mm Year: 2004
